Spesifikasi dasar - umum

Tipe Baterai:
DC7.2V
Koneksi:
SDI Out: BNC x 1, 0.8Vp-p, 75 HD: SMPTE292M/296M/299M Standard SD: SMPTE259M-C/272M-A/ITU-R.BT656-4 Standard Analog Component Output: Component Video Terminal x 1, Y: 1.0Vp-p, 75 Ohm , PB/PR: 0.7Vp-p, 75 Ohm Analog Composite Output: Pin jack x 1, 1.0Vp-p, 75 Ohm XLR Input: XLR (3-pin) x 2 (Input 1/Input 2) Input High-Impedance Line: 0dBu, MIC: -50/-60dBu (selectable in menu GUI) Line Output: Pin-jack x 2 (ch1,ch2) 316mV, 600 Ohm Built-in Microphone: Stereo microphone Phones: Stereo mini jack (3.5mm diameter) Built-in Speaker: 20mm round shape x 1 IEEE 1394: 6-pin Digital x 1 (Input/Output), based on IEEE 1394 standard USB: Type mini B connector (USB ver.2.0) Camera Remote: 2.5mm diameter super mini jack for zoom and rec start/stop 3.5mm diameter mini jack for focus and iris

Compact

Finder:
ya

Design

Colours:
black

Movie

Resolusi:
1920x1080 - Full HD

Lens features

Optical Zoom:
13x

General

Shape:
Horizontal
LCD Monitor:
3.5inch

Image sensor

Optical Sensor Type / Size:
3CCD, 1/3-inch

Ukuran

Dimensi (WxHxD):
154 × 179.5 × 397 mm
Berat:
1.9 camcorder only
